Test Plan Software
MIL-STD-1553 Protocol Testing
The PBA.pro-SCR-PTP-P scripting package is designed to run the MIL-STD-1553 Protocol Tests in accordance with the SAE AS4112 Remote Terminal Production Test Plan. This package requires the use of AIM’s MIL-STD-1553 test & simulation cards and the PBA.pro Databus Analyser & Analysis Software.
The PBA.pro-SCR-VTP-P scripting package is designed to run the MIL-STD-1553 Protocol Tests in accordance with the SAE AS4111 Remote Terminal Validation Test Plan. This package requires the use of AIM’s MIL-STD-1553 test & simulation cards and the PBA.pro Databus Test & Analysis Software.
MIL-STD-1553 Electrical Waveform Testing and Measurement
The PBA.pro-SCR-PTP-E scripting package supports the validation of MIL STD-1553 Electrical Waveform Tests in accordance with the SAE AS4112 Remote Terminal Production Test Plan. This package takes full advantage of AIM’s MILScope MIL-STD-1553 test & simulation cards which have the onboard integrated Digital Scope function used with the PBA.pro Databus Test & Analysis Software.
ARINC664 Switch and End System Testing
The PBA.pro-SCR-SW-TEST and PBA.pro-SCR-ES-TEST scripting packages support the compliance testing of ARINC664 Switches and End Systems. These packages require the use of AIM’s AFDX®/ARINC664P7 test & simulation cards and the PBA.pro Databus Test & Analysis Software. These packages comprise also the dedicated test requirements and plan documents, developed by AIM against the ARINC664P7 standard for full back traceability.
STANAG3910 Protocol and Optical Testing
For Protocol Testing of STANAG3910 equipment AIM can offer a script package for the TRD–J–017–E–0002 based EFABus Remote Terminal Interface Production Test Plan. This package requires the use of AIM’s STANAG3910 test & simulation cards and the PBA.pro Databus Test & Analysis Software.
With the strong expertise on STANAG3910 testing, AIM can also offer solutions for the testing of the optical interfaces of STANAG3910 equipment using AIM’s STANAG3910 test & simulation cards and the PBA.pro Databus Test & Analysis Software plus a dedictaed optical test module hardware, which typcially has to be tailored to the end user’s test environment and UUT specifics.
